Fluke 717-1G Pressure Calibrator

Model: 717-1G

Pressure Calibrator -1 to 1 PSI, (-68.9 mbar to 68.9 mbar, -83 to 6.89 kPa).

Traceable Calibration Certificate for your 717-1G Pressure Calibrator

1 to 2 Weeks

$2,324.99 USD



Fluke 717-1G Offers

Compact and professional pressure calibration tools.

Fluke 717-1G Pressure Calibrator is a compact, lightweight and easy to carry calibrator that delivers outstanding performance, durability and reliability. The Fluke 717 Calibrator is EMI tolerant, dust and splash resistant and features a removable battery door for quick battery changes.
The Fluke 717 simultaneously measures pressure and mA and delivers 24 volt loop supply while measuring mA.
This new Pressure Calibrator presents cost-effective solutions for highly accurate pressure measurements over a wide range of temperatures. Connect it with any of the Fluke pressure modules to address a wide variety of gage, differential, absolute, vacuum and dual (compound) pressure applications.

Measure:

  • Temperature from Thermocouple output
  • Loop Current
  • Pressure, 0.05% of full scale
  • Temperature from RTD output
  • Pressure to 10,000 psi/69 mPa using one of 29 Fluke pressure modules
  • Pressure, 0.05% of full scale with internal 100 psig sensor

Fluke 717-1G Specifications

Measurement Accuracy
Pressure
717 Series
Measure Pressure (internal sensor)
Accuracy 0.05% full scale
Functions Zero, Min, Max, Hold, Damp

 Note Gasses / liquids (non-corrosive)

Fluke 717 1G
Range -1 to 1 PSI, (-68.9 mbar to 68.9 mbar, -83 to 6.89 kPa)
Resolution 0.0001 PSI, 0.001 mbar, 0.0001 kPa
Over Pressure 5 X Full Scale

Fluke 717 Series with Pressure Modules
Measure Pressure (via pressure module connector using optional Pressure Modules)
Range 29 pressure modules, 0-1 inH20 to 10,000 PSI, 2.5 mbar to 700 bar ranges. Over pressure per pressure module specs
Resolution Per pressure module specs
Accuracy per pressure module specs
Functions Zero, Min, Max, Hold, Damp
Current
Range: 0 to 24 mA (-25% to 125%)
Resolution 0.001 mA
Accuracy 0.015% + 2 counts

Specifications
Loop Power
Range 24 V dc
Accuracy +/- 10%

 Note: Drive; 20 mA into 1000 ohms for battery >6.8V; 700 W for battery 5.8 to 6.8 V
Display

 Clear 5 digit LCD

Environmental Specifications
Operating Temperature

-10 ºC to 55 ºC
Storage Temperature

-40 ºC to 60 ºC
Humidity (Without Condensation)

95% (10 ºC to 30 ºC)

75% (30 ºC to 40 ºC)

 45% (40 ºC to 50 ºC)

 35% (50 ºC to 55 ºC)
Operating Altitude

 3,000 M max

Safety Specifications
Safety

 CSA C22.2 No. 1010.1:1992

Mechanical & General Specifications
Size

 201 mm L x 98 mm W x 52 mm (7.93in. L x 3.86in. W X 2.06in.)
Weight

22 oz, approximately 600G with holster
Warranty

 3 years
Shock & Vibration

 Random, 2G, 5-500 Hz

 1m drop test
Battery type

 Single 9V battery ANSI/NEDA 1604A or IEC 6LR619V alkaline
Click here for complete specifications on the Fluke 717-1G

What's included with the Fluke 717-1G

  • Test Leads and Alligator Clips
  • NIST- Traceable Calibration Report and Data
  • Instructions Sheet (14 languages)
  • Protective Yellow Holster with Test Lead Storage
  • Single 9V Alkaline Battery
