Fluke 719-30G Pressure Calibrator, 30 PSI

Model: 719-30G

Electric pump for one-handed pressure calibration. Best in class pressure measurement uncertainty of 0.025%.

Add In-House Traceable Calibration to your 719-30G


1 to 2 Weeks

$3,539.99 USD

Need a quote?




Fluke 719-30G Offers

Forget the Hassle of Hand Pumping
Now you can calibrate and test pressure devices quickly and easily with one hand, saving valuable time. With the innovative, built-in electric pump, the Fluke 719 Electric Pressure Calibrator provides pressure calibration at your fingertips!
Use the programmable pump limit settings to eliminate over-pressurization, and to set pump to' pressure values. The unique cleanout port design reduces pump failures, and makes the 719 easy to clean without repair. The compact, lightweight form, combined with one-handed calibration, makes this pressure calibrator the ideal tool for busy process professionals.
Pressure calibration made easy, by a name you know and trust for all your process calibration needs.

Fluke 719-30G Specifications

General Specifications
Storage temperature

-30 °C to 60 °C
Operating temperature

-10 °C to 55 °C
Relative humidity

95 % (-10 °C to 30 °C)

75 % (30 °C to 40 °C)

45 % (40 °C to 50 °C)

35 % (50 °C to 55 °C)
Shock

1 meter drop test
Safety

CSA C22.2 No. 1010.1:1992
EMC

EN50082-1:1992 and EN55022:1994 Class B
Size (HxWxL)

60 mm x 87 mm x 210 mm

(2.19 in x 3.41 in x 8.28 in)
Weight

912 g (2 lb)
Battery

Two 9 V alkaline batteries
Battery life

12 hours with 12 mA into 500 Ω, 200 pump cycles to 100 psi, 500 pump cycles to 30 psi
Warranty

Three-years, one year for pump

Specification
Fluke-719 30G
Range -12 to 36 psi, -850 mbar to 2.4 bar
Resolution 0.001 psi, 0.1 mbar
Accuracy 0.025 % range for 6 months

0.035 % of range for one (1) year
Fluke-719 100G
Range -12 to 120 psi, -850 mbar to 8 bar
Resolution 0.01 psi, 1 mbar
Accuracy 0.025 % range for 6 months

0.035 % of range for one (1) year
mA
Range 0 to 24 mA
Resolution 0.001 mA
Accuracy .015 % Rdg + 2 counts
Notes Max load, 1000 Ω, 750 Ω ohm in HART mode
Loop supply
Range 24 V dc
Resolution N/A
Accuracy ± 10 %

Pump specifications
Maximum pressure generation

120 PSI (8 BAR) (100 PSI model)
Pump to

- 30 PSI in less than 15 seconds*

- 100 psi in less than 45 seconds*

*(with 1 meter of 1/8 inch test hose)
Pump cycles between rebuilds

5000
Total pump life

20,000 calibration cycle

Click here for complete specifications on the Fluke 719-30G

What's included with the Fluke 719-30G


  • TL75 Test leads
  • AC72 Alligator clip set
  • Push fit connectors
  • Translucent test hose
  • Product overview manual (print), and
  • User's manual (CD-ROM) in 14 languages
