Model: A3002FC
Wirelessly receives and pass measurements from the i410 or i1010 AC/DC clamps accessories and other Fluke Connect™ enabled master units with this wireless AC/C current module.
Fluke Connect enabled AC/DC Current Module
The Fluke a3002 FC current module wirelessly relays measurements from a current clamp accessory to Fluke Connect enabled master units. The a3002 FC was designed to be used with the i410 or i1010 AC/DC current clamps (not included).
Capable of measuring up to 400A AC/DC when used with the i410 current clamp, and either 600A AC or 1000A DC when combined with the i1010 current clamp. Internal logging feature allows for up to 65,000 readings to be stored. The a3002 FC can be utilized as a standalone unit or combined with other Fluke Connect modules, allowing you to completely customize your wireless test tool suite.
| Function | Range | Resolution | Accuracy1 |
|---|---|---|---|
| A dc | 1000 A | 0.1 A | (0.5 % + 3) |
| A ac | 600.0 A | 0.1 A | (1.0 % + 3) |
1AC accuracy is specified from 45 Hz to 1000 Hz
| Maximum voltage between terminal and earth ground (module) | 30 V dc or ac rms |
|---|---|
| LCD w/backlight | 3.5 digits, 6000 counts, 4/sec update rate |
| Log rate/Interval | Adjustable by PC from 1 sec to 1 hr, default 1 min |
| Battery type | 2 AA Alkaline batteries, NEDA 15A, IEC LR6 |
| Battery life | 400 hours minimum |
| Memory | Record up to 65,000 readings |
| RF communications | 2.4 GHz ISM Band |
| RF communication range | Open air, unobstructed: Up to 20 m Obstructed, sheetrock wall: Up to 6.5 m Obstructed, concrete wall or steel electrical enclosure: Up to 3.5 m |
| Operating temperature | -10 °C to +50 °C |
| Storage temperature | -40 °C to +60 °C |
| Temperature coefficient | 0.1 X (specified accuracy)/°C (< 18 °C or > 28 °C) |
| Relative humidity | 0 % to 90 % (0 °C to 35 °C), 0 % to 75 % (35 °C to 40 °C), 0 % to 45 % (40 °C to 50 °C) |
| EMC | IEC 61236-1, Portable |
| Safety compliance | Protected to IEC 61010-1, 600 V CAT IV / 1000 V CAT III, 3rd edition Pollution Degree 2 |
| Certifications | CSA, CE, FCC: T68-FBLE IC: 6627A-FBLE |
| Ingress Protection (IP) rating | IP42 |
| Size (HxWxD) | 160 mm x 66 mm x 38 mm (6.3 in x 2.6 in x 1.5 in) |
| Weight | 0.255 kg (9 oz) |
Fluke engineers have delivered an innovative mobile platform and tool that helps solve everyday problems, allowing you to instantly document measurements, retrieve historical data, and share live measurements with your team. All handled by the Android™ or iOS smart phone you already carry.
Fluke Connect with ShareLive™ video call is the only wireless measurement system that lets you stay in contact with your entire team without leaving the field. The Fluke Connect mobile app is works with over 20 different Fluke products - the largest suite of connected test tools in the world.
Make the best decisions faster than ever before by viewing temperature, mechanical, electrical and vibration measurements for each equipment asset in one place. Get started saving time and increasing your productivity.
Click on a category to view a selection of compatible accessories with the Fluke A3002 FC Wireless AC/DC Current Module.
