Fluke 721EX Series Dual Sensor Pressure Calibrators

Model: 721EX Series

Range: 16 psig
Range: 36 psig

Ideal for gas flow calibration (custody transfer) applications allowing you to take simultaneous static and differential pressure measurements with a single tool. Intrinsically Safe - IECEx and Atex Ex ia IIB T3 Gb (Zone 1).

Ordering Information

Help with Ordering

Fluke 721EX Series Offers

Features

Can be configured by selecting either a 16 psi (1.1 bar) or 36 psi (2.48 bar) low pressure sensor then add any of 7 high pressure ranges including 100, 300, 500, 1000, 1500, 3000 or 5000 psi (6.9, 20, 24.5, 69, 103.4, 200, 345 bar)
Two isolated, stainless steel, pressure sensors with 0.025% accuracy
Switch test on both pressure inputs
Pressure displayed in the user's choice of 19 engineering units: psi, bar, mbar, kPa, kgcm², cmH₂O @ 4°C, cmH2O @ 20°C, mH₂O @ 4°C, mH₂O @ 20°C, inH₂O @ 4°C, inH₂O @ 20°C, inH₂O @ 60°F, mmHg @ 0°C, inHg @ 0°C, ftH₂O @ 4°C, ftH₂O @ 20°C, ftH₂O @ 60°F
Precision temperature measurement with optional RTD probe
Measures 4 to 20 mA signals
Large backlit graphic display shows up to three inputs simultaneously
Store five instrument setups for recall and use

Application Selection Guide


Model number	754	721/721Ex	719Pro	719	718	717	700G	3130	2700G	Dead-weight Testers
Application
Calibrating pressure transmitters (field)	●	●	Ideal	●	●	●		●
Calibrating pressure transmitters (bench)	●	●	●	●	●	●		Ideal		●
Calibrating HART Smart transmitters	Ideal
Documenting pressure transmitter calibrations	Ideal
Testing pressure switches in the field	Ideal	●	●	●	●	●		●
Testing pressure switches on the bench	●	●	●	●	●	●		Ideal
Documenting pressure switch tests	Ideal
Testing pressure switches with live (voltage) contacts	Ideal
Gas custody transfer computer tests	●	Ideal	●
Verifying process pressure gauges (field)	Ideal	●	●	●	●	●	●
Verifying process pressure gauges (bench)	●	●	●	●	●	●		●	●	Ideal
Logging pressure measurements	●						Ideal		●
Testing pressure devices using a reference gauge									Ideal
Hydrostatic vessel testing							Ideal
Leak testing (pressure measurement logging)	●						Ideal

Pressure Calibration Selection Guide

Fluke 721EX Series Specifications

Pressure Range	Available from 16 to 36 psi (1.1 to 2.48 bar) with 7 high pressure ranges including 100, 300, 500, 1000, 1500, 3000 or 5000 psi (6.9, 20, 24.5, 69, 103.4, 200, 345 bar)
Resolution	0.001 psi (0.0001 bar)
Accuracy	±0.025% f.s.
Current Range	0 to 24mA
Resolution	0.001mA
Accuracy	±0.015% of rdg ±0.02 ohms; ±0.1°C (±0.2°F) ±0.25°C (±0.45°F) combined uncertainty when using 720 RTD probe accessory
Loop Supply Range	24V
Temperature Range	-40 to 150°C (-40 to 302°F)
Connectors/Ports	Two, 1/8" NPT, 750P Series Pressure Module RTD Probe
Power Supply	(4) standard AA batteries
Dimensions	7.9 x 4.3 x 2.3 (20 x 11 x 5.8 cm)
Weight	035 kg (1 lb 3 oz)

What's included with the Fluke 721EX Series

721EX-1601 Dual Sensor Pressure Calibrator
Test leads
4 AA batteries
Manual
Calibration certificate
Soft case
