Fluke FLK-100-ML

Model: FLK-100-ML

4" (100Mm) M-Range IR Window. Must Be Ordered In Multiples Of 10.

Sorry! This product has been discontinued.


The Fluke FLK-100-ML has been discontinued, it has been replaced by the Fluke FLK-075-CLV IR Window 3" (75mm) for Indoor Low Voltage





Increase the safety and speed of indoor and outdoor electrical thermography with these UL and CSA certified IR Windows. These IR Windows come in three diameters: 2", 3" or 4".

Fluke IR Windows are the most rugged on the market, with a heavy duty aluminum housing and arc-flash resistance to increase safety when conducting thermal inspections.

With a Kwik Twist cover that magnetically sticks to the panel when removed, Fluke IR Windows are easy to use and deliver unmatched image clarity through a CLIRVU® crystal. Exclusive to Fluke IR Windows, CLIRVU crystal technology is impervious to both moisture and vibration. CLIRVU crystals are designed to withstand the extreme pressures and temperatures of an arc-fault event, and offer protection from molten projectiles associated with arc-flashes.

  • Engineered and tested to withstand electric-arcs up to 50 kA for30 cycles.
  • Certified by UL & CSA for Type 3/12 (Outdoor) environments in North America, these C-Range windows are tested to withstand the long term aging effects of UV exposure.
  • Certified by SIRA Certification IP65 (Outdoor) environments in Europe.
  • The CLIRVU® coating-exclusive to Fluke IR Windows-seals the optic prior to assembly to protect against moisture degradation.
  • Own a Fluke Camera? The Quadraband™ optic is IR-Fusion® compatible, allowing the thermographer to see potential problems in visual light and thermographic mode.
  • Got more than one window per panel? Each C-Range window is delivered with an identification plate attached for unique, on-site numbering for rapid location confirmation and faster repairs.
  • Each infrared window comes complete with a security access key, installation instructions and self-adhesive drilling template.
Detailed Specifications
Optic data
Crystal insert diameter
3460346 FLK-050-CLKT   50 mm (1.97 in)
3460387 FLK-075-CLKT   75 mm (2.96 in)
3460439 FLK-100-CLKT   100 mm (3.94 in)
Viewing aperture diameter
3460346 FLK-050-CLKT   43 mm (1.7 in)
3460387 FLK-075-CLKT   68 mm (2.7 in)
3460439 FLK-100-CLKT   89 mm (3.5 in)
Viewing aperture area
3460346 FLK-050-CLKT   1452 mm2 (2.25 sq in)
3460387 FLK-075-CLKT   3632 mm2 (5.63 sq in)
3460439 FLK-100-CLKT   6322 mm2 (9.79 sq in)
Thickness
3460346 FLK-050-CLKT   2 mm (0.08 in)
3460387 FLK-075-CLKT   2 mm (0.08 in)
3460439 FLK-100-CLKT   4 mm (0.16 in)
CLIRVU coating
3460346 FLK-050-CLKT   Yes
3460387 FLK-075-CLKT   Yes
3460439 FLK-100-CLKT   Yes
Shortwave IR capable
3460346 FLK-050-CLKT   Yes
3460387 FLK-075-CLKT   Yes
3460439 FLK-100-CLKT   Yes
Midwave IR capable
3460346 FLK-050-CLKT   Yes
3460387 FLK-075-CLKT   Yes
3460439 FLK-100-CLKT   Yes
Longwave IR capable
3460346 FLK-050-CLKT   Yes
3460387 FLK-075-CLKT   Yes
3460439 FLK-100-CLKT   Yes
Ultraviolet (UV) capable
3460346 FLK-050-CLKT   Yes
3460387 FLK-075-CLKT   Yes
3460439 FLK-100-CLKT   Yes
Visual capable
3460346 FLK-050-CLKT   Yes
3460387 FLK-075-CLKT   Yes
3460439 FLK-100-CLKT   Yes
Fusion capable
3460346 FLK-050-CLKT   Yes
3460387 FLK-075-CLKT   Yes
3460439 FLK-100-CLKT   Yes
Underwriters Laboratories (UL) recognized Yes
UL50 environmental
Type 3/12
UL746C
N/A (Polymer Free)
UL94
N/A (Polymer Free)
Canadian Standards Association (CSA) approval Yes
Environmental
Type 3/12
KEMA (Arc-Testing)
ANSI C37.20.7
50 kA for 30 cycles @60 Hz
EEMACS 14-1 Type-B
40 kA for 30 cycles @60 Hz
ASTA (Arc-Testing)
IEC 62271
20 kA for 5 cycles @50 Hz
TUV
Cyclic humidity withstand
Yes
Vibration withstand
Yes
NEMKO
Resistance of insulating materials to 100°
Yes
Resistance of insulating material to ball pressure (Brinell)
Yes
Glow-wire test 650 °C
Yes
Lloyds Register
Up to 11 kV marine switchgear, indoor or outdoor
Yes
Click here for complete specifications on the Fluke FLK-100-ML
