Fluke 717-3000G Pressure Calibrator

Model: 717-3000G

Pressure Calibrator 0 to 3000 PSI, (0 bar to 207 bar, 0 to 20684.27 kPa).

Add In House NIST Traceable Calibration to your 717-3000G

Clear selected options

$1,599.99 USD

6 to 7 Weeks


  • Measure pressure, 0.05% of full scale with internal sensor up to 5000 PSI/345 bar sensor (5000G model)
  • Measure mA with 0.015% accuracy and 0.001 mA resolution, while sourcing 24V loop power
  • Measure pressure to 10,000 psi/700 bar using one of 29 Fluke 700Pxx Pressure Modules
  • 1/8 NPT female pressure fitting
  • Compatible with non-corrosive Gases and liquids
  • Select eleven different engineering units
  • Zero, min, max, and hold functions
  • Calibrate P/I instruments with simultaneous pressure and current measurement
  • Pressure switch test function captures set, reset and Deadband values of a pressure switch
  • Error% calculation of mA measurements for quick pass-fail decisions
  • Long lasting battery life
  • Holster features test lead storage
  • Compatible with Toolpack magnetic hanging system
  • New switch test

Compact and professional pressure calibration tools.

Fluke 717-3000G Pressure Calibrator is a compact, lightweight and easy to carry calibrator that delivers outstanding performance, durability and reliability. The Fluke 717 Calibrator is EMI tolerant, dust and splash resistant and features a removable battery door for quick battery changes.
The Fluke 717 simultaneously measures pressure and mA and delivers 24 volt loop supply while measuring mA.
This new Pressure Calibrator presents cost-effective solutions for highly accurate pressure measurements over a wide range of temperatures. Connect it with any of the Fluke pressure modules to address a wide variety of gage, differential, absolute, vacuum and dual (compound) pressure applications.


  • Temperature from Thermocouple output
  • Loop Current
  • Pressure, 0.05% of full scale
  • Temperature from RTD output
  • Pressure to 10,000 psi/69 mPa using one of 29 Fluke pressure modules
  • Pressure, 0.05% of full scale with internal 100 psig sensor
Measurement Accuracy
717 Series
Measure Pressure (internal sensor)
Accuracy 0.05% full scale
Functions Zero, Min, Max, Hold, Damp

Note Gasses / liquids (non-corrosive)
Fluke 717 3000G
Range 0 to 3000 PSI, (0 bar to 207 bar, 0 to 20684.27 kPa)
Resolution 0.1 PSI, 0.01 bar, 1 kPa
Over Pressure 2 X full scale
Fluke 717 Series with Pressure Modules
Measure Pressure (via pressure module connector using optional Pressure Modules)
Range 29 pressure modules, 0-1 inH20 to 10,000 PSI, 2.5 mbar to 700 bar ranges. Over pressure per pressure module specs
Resolution Per pressure module specs
Accuracy per pressure module specs
Functions Zero, Min, Max, Hold, Damp
Range: 0 to 24 mA (-25% to 125%)
Resolution 0.001 mA
Accuracy 0.015% + 2 counts

Loop Power
Range 24 V dc
Accuracy +/- 10%

Note: Drive; 20 mA into 1000 ohms for battery >6.8V; 700 W for battery 5.8 to 6.8 V

Clear 5 digit LCD

Environmental Specifications
Operating Temperature

-10 C to 55 C
Storage Temperature

-40 C to 60 C
Humidity (Without Condensation)

95% (10 C to 30 C)

75% (30 C to 40 C)

45% (40 C to 50 C)

35% (50 C to 55 C)
Operating Altitude

3,000 M max

Safety Specifications

CSA C22.2 No. 1010.1:1992

Mechanical & General Specifications

201 mm L x 98 mm W x 52 mm (7.93in. L x 3.86in. W X 2.06in.)

22 oz, approximately 600G with holster

3 years
Shock & Vibration

Random, 2G, 5-500 Hz

1m drop test
Battery type

Single 9V battery ANSI/NEDA 1604A or IEC 6LR619V alkaline

Click here for complete specifications on the Fluke 717-3000G
